SC Stereo Channel

175,00  + VAT

In stock

Description

The Stereo Channel is a single-channel stereo module for the CGM Eurorack mixer, fully compatible with every other product of this family.

Thanks to its advanced I/O configuration, it can work as stereo-to-stereo, mono-to-mono, mono-to-stereo, and stereo-to-mono.

The gain control and the two mono FX sends can work in pre or post-fader mode, and the panpot can also work as a dual mono crossfader, making it suitable for blending two mono sources into a single mono sum.

All the parameters are voltage-controllable for creative mixing automation.

Electronic latching mute, PFL, and Solo-in-Place complete the feature set suitable both for studio and live performances.

Key Features

Thanks to a flexible I/O semi-normalization pattern, you can use the SC in other ways than stereo. You can patch a mono signal and record it in stereo straight after the VCA to track the voltage-controlled panning or blend two mono sources into one, and more.

The Channel module features two amplitude controls: an input VCA and a volume fader. The input VCA is voltage-controllable and, if the signal has enough amplitude, it can overdrive the circuit with a creamy, fat saturation. A peak LED tells when the signal is clipping, but don’t fear cranking it up!

An output allows you to take the channel output for parallel processing or multitrack recording. You can choose to work pre-fader (straight after the input VCA) or post-fader (with the main fader affecting the signal’s amplitude). The outputs are semi-normaled: use just the left output for a mono sum, and both channels for a stereo signal.

The mute button allows you to remove a channel from the group sum with a click. The mute function works over the input VCA, so it will also mute the effect sends.

The yellow and green knobs are two effect sends levels. They can work pre- or post-fader, and they can be voltage-controlled for expressive and creative results.

The Pan knob defines the stereo placement of the sound, which you can voltage-control as well. The Pan/Crossfade switch lets you use the SC as a dual mono mixer, blending two mono signals into a mono output. When in Crossfade mode, the pan pot controls the balance of the two inputs.

The mute button allows you to remove a channel from the group sum with a click. The mute function works over the input VCA, so it will also mute the effect sends.

The Solo-In-Place switch lets you prepare a “scene” of channels to be isolated from the other ones, and then recall it through the Safe Solo switch on the Group module. It can be seen as a mute group function that allows you to mute all the channels outside the solo scene with a click.

Push the PFL button and rotate the PFL fader on the master module to preview a channel: it’s convenient for tuning your oscillators or checking if everything is ok before bringing whatever sound source into the mix.

Channel Family Comparison

Channel circuits

1

1

4

Mono/Stereo

Mono

Stereo/Dual mono

Stereo/Dual mono

Pan

Pan

Pan/Crossfade

Pan/Crossfade

CV over VCA

CV over pan

2 (on ch. 1 and 4)

CV over sends

2

2 (yellow on ch. 1, green on ch. 4)

FX sends per channel

2

2

2

FX sends circuit

Pre-/Post-fader

Pre-/Post-fader

Pre-/Post-fader

Channel output

Mono Pre-/Post-fader

Mono/stereo Pre-/Post-fader

Stereo Post-fader local mix

Mute

Mechanical latching

Electronic latching

Electronic latching

Solo in place

Mechanical latching

Mechanical switch

Mechanical switch

PFL

Mechanical latching

Electronic latching

Electronic latching

Fader knob

⌀ 20 mm

⌀ 12 mm

⌀ 12 mm

Additional inputs

Mono aux in

Additional outputs

2 local mono FX sends

Learn

Learn

Learn

Additional information

Weight 0,161 kg
Dimensions 15,6 × 6 × 6 cm

Specs

Size

6 HP

Depth

38 mm

Current draw

70 mA @ +12 V

45 mA @ -12 V

Recommended warmup time

30 min

Audio input impedance

> 10 KΩ (mono)

> 20 KΩ (stereo)

Audio output impedance

≥100 Ω

CV Input impedance

> 90 KΩ

Maximum output level before clipping

≥ 17 dBu

Direct output gain scale

11 dB

Send to G/G (2016) gain scale

18 dB

Frequency response

0.01 to 40 KHz

Harmonic distortion

< 0.3 %

Panpot center position tolerance

< 1.5 dB

Max VCA attenuation

≤ 70 dB

More details on the Manualone.

FAQ

c Expand All C Collapse All

A. Use

Our modules are packed with high-quality components that demand a proper power supply and can get sensibly warm.

That is its normal temperature and we can guarantee their performance.

You always need at least one group if you plan to incorporate a master module in your setup. It is not possible to connect any channel module directly to a master module.

The CGM is designed to let you connect up to eight channels (C or QSC) to one group (G), but there is no way of connecting the same channels to two or more groups.

Yes, to take advantage of the Master module’s functions (PFL, headphones, final gain stage), you need at least one group.

We designed the group (G) module together with the classic mono channel (C), which is 6HP wide. After the QSC release, we developed a new Link System with wider plugs that allow you to connect more QSCs in a row.

If you need to connect more QSCs, check your local shop for cable availability!

If you just need to connect a QSC, the classic group-to-channel cable works great, too.

If you experience an abnormal panning on the CGM, check your case’s power supply and your system’s overall power consumption. We experienced that the CGM system sometimes has trouble working in a system close to its maximum Ampère output. An unbalanced power supply may cause the audio to be louder on one channel than on the other.

Try staying below 80% of the total amperage or switch to a more powerful PSU to solve this issue.

The Mute button closes the first VCA of the channel, thus preventing the sound from being routed through all the other VCAs (FX sends, pan, main fader).

The Solo in Place button isolates some channels and mutes the others. However, the mute function it performs is different since it affects the channel after the fader: the sound will still be routed to any pre-fader VCA such as Direct Output and FX Sends (when set to Pre-Fader Mode).

In other words, the Mute button works pre-fader, while the Solo in Place works post-fader.

B. Design

We have two main kinds of capacitors.

The first one is necessary to AC-couple the audio signal: they prevent any unwanted DC offset, and they offer protection against wrong connections. For this reason, you can patch nearly every input to every output, and the worst thing that can happen is some pops or some silence.

The second one is power filters to guarantee a cleaner current flow across the case. They might sound a bit over the top, but we must remember that a Eurorack system is not something that comes straight out of the factory. Instead, every Eurorack setup is unique and may change according to the musician’s need. For this reason, we want to add as much protection as we can, both to avoid issues with our modules and to ensure that even the other modules behave correctly. We use a wide mix of capacitors in our modules: ceramic, electrolytic, tantalum, and multilayer. They can be assembled thru-hole or SMD, according to what gives the best balance between result and space. For example, all the electrolytic capacitors are mounted thru-hole because they perform better according to our tests.

However, the capacitors have zero impact on the power draw, on which you can read in this other FAQ.

Power draw should always be related to what a module does.

Generally speaking, there are modules like SAPÈL that undoubtedly consume more than other random generators. However, SAPÈL is a double module, so a fair comparison would be between it and a pair of similar modules. The same can be said for FUMANA, the most power-demanding filter bank. However, it is also the only Eurorack filter bank with 32 analog bandpass filters, half of which have a 48 dB/oct slope. So, also in this case, a fairer comparison would be between FUMANA and TWO other 16-band filter banks, which leads to similar power consumptions.

More in detail, we engineer our modules to be safe to use. To protect both the modules and the rest of the case, we add a proper buffering stage to every input and output: even if a single buffer doesn’t draw that much power, all the ins and outs piled together can significantly impact the final power draw.
